Glass Fused Steel Sealant Tank
Glass-Fused-to-Steel (GFS) tanks, also known as Glass Lined Steel (GLS) tanks, represent a premium technology in the tank market. The fusion of glass and high-tensile mild steel combines the best properties of both materials. Steel provides strength and flexibility, while glass offers corrosion resistance.
This fusion eliminates the need for painting in the future, as the tank is inherently protected against corrosion by the glass enamel coat. One of the significant advantages of GFS tanks is the widening of the acceptable bracket of pH values after the fusion of steel with glass. This means that the tanks can withstand a wider range of pH levels without compromising their integrity.
Moreover, the application of Glass-Fused-to-Steel technology to both interior and exterior surfaces ensures that the tanks can withstand harsh environments for many years without encountering significant issues. This durability makes GFS tanks an excellent choice for various industrial, municipal, and agricultural applications where reliability and longevity are crucial factors.
GFS Tanks with Sealant: These tanks utilize a high-performance sealant to secure joints and seams, providing robust protection against leaks and corrosion.
GFS Tanks with Liner: These tanks come with a specialized internal liner that provides an additional layer of protection, ensuring enhanced durability and corrosion resistance.
Liner: The liner is a protective barrier that shields the tank’s interior from chemical reactions, corrosion, and external contaminants, significantly extending the tank’s service life.
Design Standards for Glass-Fused-to-Steel (GFS) Tanks
AWWA D103: This standard is published by the American Water Works Association (AWWA) and provides guidelines for the design, construction, and inspection of bolted steel tanks for water storage.
Adhering to these standards ensures that GFS tanks meet the necessary safety, quality, and performance criteria required for water storage and fire protection applications. Compliance with AWWA D103-09 and FM 4020 standards also helps ensure consistency and interoperability in the design and construction of GFS tanks across different projects and locations.
Glass Fused Steel Tank – Process and Technology
A brief process of creating Glass-Fused-to-Steel (GFS) tanks involves several precise steps to ensure the quality and integrity of the finished product:
- Nut & Bolt holes and manhole drilling/punching
- Shot blasting process
- Enamelling Process
- Quality Check
Here’s an overview of the typical quality check process –
- Spark Test
- DFT
- Impact test
- Visual test (for liner)
- Light test (for liner)
Installation Process
A. Top-to-Bottom Assembly
- Start by assembling the top ring and roof.
- Use jacks to lift the structure.
- Add subsequent rings from the top down by bolting them beneath the existing assembly.
B. Adding Rings & Accessories
- Continue ring installation, progressively adding new rings at the bottom as the structure is lifted.
- Install ladders, manholes, nozzles, and other accessories during this stage, based on the tank design and layout.
C. Anchoring
- After full assembly, anchor the tank to the foundation.
- Use J-bolts or chemical fasteners to ensure structural stability and resistance to uplift or lateral loads.
Types of Roofs We offer-
- Dome Roof – ZA / FBEC
- Conical Roof – ZA / FBE / GFS
- PVC Double membrane liner roof
- GFS fixed leakproof roof
- Geodesic Roof
MATERIAL CODES
- Sheet – IS2062.
- Nuts And Bolts – ISO 898 – 1
- Anchors – 8.8 Grade
- PU Sealant – Migration Behaviour EN 1186, EN 13130, CEN/TS 14234, ISEGA, Certificate No. 46763 U 18
- Sewage Installations wastewater, As Per Report No 36142/98
KEY ADVANTAGES OF ROSTFREI Glass Fused Steel TANKS
Applications of Glass Fused Steel Tanks
Glass Fused Steel Sealant Tanks offer extensive applications across multiple industries, delivering reliable and long-lasting storage solutions for water, wastewater, industrial processes, and fire protection systems.
Color Options Available
Rostfrei Glass Fused Steel Tanks are available in multiple aesthetically appealing colour finishes, ensuring excellent visual appeal while maintaining superior corrosion resistance.
